iButton® MissionCheck™


Price:
Sale price$114.99

Description

The iButton® MissionCheck™ is part of the iButton® Typer™ family, specially programmed to input the temperature and humidity alarms of Maxim iButtons® into an open word processing program, letting you know if any of the alarms have been triggered. This compact, water-resistant device is great for use in cold chain shipments or in other applications where keeping a close eye on temperature is important.

Simply plug the iButton® MissonCheck™ into a USB port on your computer, open a word processing program, and hold the iButton® on the read head. There are no drivers that need to be installed, no set-up, and no product registration.  The iButton® MissionCheck will input the alarm information of the iButton® held on the read head where the cursor is placed in an open word processing program in the font style and size specified in the document. You can use your choice of program: Word®, Excel®, Notepad, and more.

Don’t use a QWERTY keyboard layout? Don’t worry, because iButtonLink engineers can also program the iButton® Typer™ to input the alarms in AZERTY as well.

Three LEDs line the side of the Technomelt-molded body and let you know the status of both the iButton® Typer™ and the iButton® on the read head. The red LED indicates that an alarm was triggered, green indicates that no alarms were triggered, and yellow indicates no alarms were set.

Additionally, the iButton® MissionCheck can be used with any USB power source, such as a USB wall charger, and the alarms from the iButton® can be read that way.

The iButton® Typer™ uses a micro-USB cable to connect to any computer running Windows (cable sold separately).

The iButton® MissionCheck is available in HID or Serial mode. Please indicate which you would like in the "special instructions" box before checking out.

iButton® Typer™ - Serial Communication: Driver Installation

  1. Download the serial communication driver zip file: Download Drivers
  2. Open zip file to extract drivers
  3. Run correct 32 or 64-bit installer depending on your system



The product manual can be found here

This product is RoHS compliant.

280000005013FD41,06/09/2021 04:20:35 PM,DS1923,Battery on reset alarm: PASS,High temperature alarm: NOT ENABLED,Low temperature alarm: NOT ENABLED High humidity alarm: NOT ENABLED,Low humidity alarm: NOT ENABLED

Example of iButton MissionCheck output™
